Drive System

6×4

Dimensions

 (L*W*H)(mm)

 Overall

9825×2490×3210

 Dump body

7000 * 2326 * 600

Thickness (mm)

Bottom 3 , side 2

Approach / departure angle (°)

16/17

Kerb weight (kg)

10900

Total mass (kg)

25000

Wheel base  (mm)

4325+1350

Overhang (F/R)  (mm)

1525/2625

Track width (F/R)  (mm)

1939 / 1800

Engine

WD615.50 (WEICHAI , Euro 2 )

Rated power

290 hp

Gearbox

9JS119 (Fast gear)

Clutch

430 Diaphragm type

Cab

F2000 Cabin with A/C &sleeper

Axle

Front

7.5 ton

Rear

13 Ton double reduction-gear axle , final ratio4.8

Tyre (radial tire)

12.00R20(10+1 spare tire)
